Materials and Construction:
The strainer is constructed from high-grade stainless steel, which is chosen for its good resistance to corrosion. This material is particularly suitable for use with aggressive chemicals, seawater, and other fluids that can cause rapid deterioration of less resistant materials. The Y Type Strainer's body is precision-engineered to provide a uniform and consistent flow path, less pressure drop and ensuring good filtration efficiency.
Design Features:
1. Y Type Configuration: The Y Type design allows for a larger filtration area, which can handle higher flow rates and reduce the frequency of cleaning or maintenance. The Y shape also facilitates easier inspection and cleaning of the strainer.
2. Flanged Connections: Flanged ends are standard on these strainers, allowing for easy installation into existing pipe systems. The flanges are designed to meet various international standards, ensuring compatibility with a wide range of industrial applications.
3. Screen or Basket Options: The strainer can be fitted with either a perforated screen or a wire mesh basket, depending on the specific requirements of the application. The screen provides a fixed size of openings, while the basket allows for customizable mesh sizes to suit different particle separation needs.
4. Manual or Automatic Cleaning: Some models of the Corrosion Resistance Stainless Steel Y Type Strainer are available with manual cleaning options, while others can be equipped with automatic self-cleaning mechanisms. This feature is particularly beneficial in applications where continuous operation is critical, and downtime for cleaning must be minimized.
Applications:
The Corrosion Resistance Stainless Steel Y Type Strainer is widely used across various industries due to its versatility and robustness. Some of the key applications include:
1. Chemical Processing: In the chemical industry, the strainer is used to remove impurities from process streams, protecting sensitive equipment such as pumps, valves, and heat exchangers.
2. Water Treatment: In water treatment facilities, the strainer is essential for removing debris and particles before the water undergoes further treatment processes.
3. Food and Beverage: The strainer is used in the food and beverage industry to ensure that product quality is maintained by removing contaminants that could affect taste, appearance, or safety.
4. Pharmaceutical: In pharmaceutical manufacturing, the strainer is crucial for maintaining the purity of products, as any contamination could have serious health implications.
5. Power Generation: In power plants, the strainer is used to protect turbines and other critical equipment from damage caused by debris in the water or steam lines.
The Corrosion Resistance Stainless Steel Y Type Strainer is a reliable and efficient solution for fluid filtration in a wide range of industrial applications. Its corrosion-resistant properties, combined with its robust design and ease of maintenance, make it a good choice for ensuring the integrity and efficiency of fluid systems in challenging environments. By choosing this strainer, industries can protect their equipment, maintain product quality, and reduce downtime, all while benefiting from the long-term durability of stainless steel.
The filter is an indispensable device in the pipeline system for conveying media. Its function is to remove mechanical impurities in the passing media to protect the accessories on the equipment pipeline from wear and blockage. At present, my country basically uses R406 type decontaminant, which is large in size, strong in the negative force, inconvenient to install, and takes a long time to discharge sewage, and the cost is high, which fails to meet the needs of the majority of users. In response to the above problems, our factory has made improvements and developed three series of filters, which are basically the same in appearance (Y-type), and the internal parts are all made of stainless steel, which is hard and durable. The filter is small in size, fine in filter mesh, small in resistance, high in efficiency, easy to install and maintain, and low in cost, which can meet the needs of various pipelines.
Technical Parameters
Nominal pressure |
1.6-2.5MPa |
Test pressure |
2.4MPa |
Working temperature |
-80℃-400℃ |
Valve body |
cast steel, stainless steel |
Filter |
stainless steel |
Structure |
shell, drain cover, filter element, filter, stud |
Main Connection Dimensions
DN |
L |
H |
25 |
160 |
80 |
32 |
180 |
90 |
40 |
205 |
100 |
50 |
210 |
130 |
65 |
250 |
160 |
80 |
285 |
180 |
100 |
310 |
185 |
125 |
350 |
230 |
150 |
380 |
260 |
200 |
480 |
340 |
250 |
550 |
400 |
300 |
610 |
440 |
350 |
700 |
530 |
400 |
850 |
570 |
500 |
900 |
650 |
